Page 086B –
Brake Lines & Hoses 8/80-2007 FJ60, FJ62, FJ/FZJ80 & UZJ100 Series
8/80-2006 60, 62, 80 and 100 Series
Click the NUMBERS in the blue squares for part listings
Click on the BLUE HIGHLIGHTED NUMBERS in the line drawings to display a COMPLETE part listing of that part number.
Part Numbers & Part Listings
8/80-1/90 60 & 62 Series
60 Series
8/87-1/90 62 Series
8/87-1/90 62 Series -
Load Sensing Proportion Valve (L.S.P.V.) #60 IS A USED ASSEMBLY
Proportioning Valves
| Buy | Quantity | Part Number | Description | Price | In Stock | Click for Zoom |
|---|---|---|---|---|---|---|
| Add to Cart | 086-60B |
BRK PROP VALVE Fits 8/80-4/86 FJ40/FJ60 (Discontinued - Not available at this time)  WARNING: Cancer and Reproductive Harm — www.p65warnings.ca.gov |
$0.00 |
|
||
|
BRK PROP VALVE Fits 8/80-4/86 FJ40/FJ60 (Discontinued - Not available at this time) WARNING: Cancer and Reproductive Harm — www.p65warnings.ca.gov |
||||||
| Add to Cart | 086-60B-A |
AFTERMARKET BRAKE PROPORTIONING VALVE Fits 8/80-4/86 FJ40/FJ60 WARNING: Cancer and Reproductive Harm — www.p65warnings.ca.gov |
$195.00 |
|
||
|
AFTERMARKET BRAKE PROPORTIONING VALVE Fits 8/80-4/86 FJ40/FJ60 WARNING: Cancer and Reproductive Harm — www.p65warnings.ca.gov |
||||||
| Add to Cart | 086-60B-U |
U BRK PROP VLV Fits 8/80-4/86 FJ40/60 USED PLEASE ALLOW 24 TO 72 HOURS TO PULL AND INSPECT ALL USED PARTS BEFORE SHIPMENT WARNING: Cancer and Reproductive Harm — www.p65warnings.ca.gov |
$296.00 |
|
||
|
U BRK PROP VLV Fits 8/80-4/86 FJ40/60 USED WARNING: Cancer and Reproductive Harm — www.p65warnings.ca.gov |
||||||
| Add to Cart | 086-60BB |
RR LOADSENP/VLV Fits 10/80-6/85 FJ/BJ45/HJ47 Special Order - NO Return WARNING: Cancer and Reproductive Harm — www.p65warnings.ca.gov |
$291.07 |
|
||
|
RR LOADSENP/VLV Fits 10/80-6/85 FJ/BJ45/HJ47 Special Order - NO Return WARNING: Cancer and Reproductive Harm — www.p65warnings.ca.gov |
||||||
| Add to Cart | 086-60BB-U |
U LOAD SENSVLV Fits 10/80-6/85 F/BJ45 USED PLEASE ALLOW 24 TO 72 HOURS TO PULL AND INSPECT ALL USED PARTS BEFORE SHIPMENT WARNING: Cancer and Reproductive Harm — www.p65warnings.ca.gov |
$188.00 |
|
||
|
U LOAD SENSVLV Fits 10/80-6/85 F/BJ45 USED WARNING: Cancer and Reproductive Harm — www.p65warnings.ca.gov |
||||||
| Add to Cart | 086-60C |
BRK PROP VALVE Fits 4/86-8/87 FJ60 (Discontinued - Not available at this time) WARNING: Cancer and Reproductive Harm — www.p65warnings.ca.gov |
$0.00 |
|
||
|
BRK PROP VALVE Fits 4/86-8/87 FJ60 (Discontinued - Not available at this time) WARNING: Cancer and Reproductive Harm — www.p65warnings.ca.gov |
||||||
| Add to Cart | 086-60C-A |
AFTERMARKET BRAKE PROPORTIONING VALVE Fits 4/86-8/87 FJ60 WARNING: Cancer and Reproductive Harm — www.p65warnings.ca.gov |
$195.00 |
|
||
|
AFTERMARKET BRAKE PROPORTIONING VALVE Fits 4/86-8/87 FJ60 WARNING: Cancer and Reproductive Harm — www.p65warnings.ca.gov |
||||||
| Add to Cart | 086-60C-U |
U BRK PROP VLV Fits 4/86-8/87 FJ60 USED PLEASE ALLOW 24 TO 72 HOURS TO PULL AND INSPECT ALL USED PARTS BEFORE SHIPMENT WARNING: Cancer and Reproductive Harm — www.p65warnings.ca.gov |
$296.00 |
|
||
|
U BRK PROP VLV Fits 4/86-8/87 FJ60 USED WARNING: Cancer and Reproductive Harm — www.p65warnings.ca.gov |
||||||
| Add to Cart | 086-60D |
REAR LOAD SENSING PROPORTION VALVE Fits 8/87-1/90 FJ62 (Discontinued - Not available at this time) WARNING: Cancer and Reproductive Harm — www.p65warnings.ca.gov |
$0.00 |
|
||
|
REAR LOAD SENSING PROPORTION VALVE Fits 8/87-1/90 FJ62 (Discontinued - Not available at this time) WARNING: Cancer and Reproductive Harm — www.p65warnings.ca.gov |
||||||
| Add to Cart | 086-60D-A |
AFTERMARKET BRAKE PROPORTIONING VALVE Fits 8/87-1/90 FJ62 WARNING: Cancer and Reproductive Harm — www.p65warnings.ca.gov |
$125.00 |
|
||
|
AFTERMARKET BRAKE PROPORTIONING VALVE Fits 8/87-1/90 FJ62 WARNING: Cancer and Reproductive Harm — www.p65warnings.ca.gov |
||||||
| Add to Cart | 086-60D-U |
USED REAR LOAD SENSING PROPORTION VALVE Fits 8/87-1/90 FJ62 Used IT APPEARS WE ARE OUT OF STOCK ON THIS ITEM. PLEASE CALL TO CHECK AVAILABILITY (818) 882-1238. WARNING: Cancer and Reproductive Harm — www.p65warnings.ca.gov |
$307.00 |
|
||
|
USED REAR LOAD SENSING PROPORTION VALVE Fits 8/87-1/90 FJ62 Used Special Order - NO Return WARNING: Cancer and Reproductive Harm — www.p65warnings.ca.gov |
||||||
| Add to Cart | 086-64K |
BRAKE PROPORTIONING VALVE BOOT AND LINK HARDWARE KIT Fits 8/87 to 1/98 62, 70 and 80 Series with variable proportioning valve. Contains dust boots, link bushings and hardware. WARNING: Cancer and Reproductive Harm — www.p65warnings.ca.gov |
$118.75 |
|
||
|
BRAKE PROPORTIONING VALVE BOOT AND LINK HARDWARE KIT Fits 8/87 to 1/98 62, 70 and 80 Series with variable proportioning valve. Contains dust boots, link bushings and hardware. WARNING: Cancer and Reproductive Harm — www.p65warnings.ca.gov |
||||||
Back to Top
Stainless Steel Braided Brake Hose
(click for large picture)
For those Cruisers who have modified suspensions, Specter offers extended Stainless Steel Braided D.O.T. approved Brake Hoses. These hoses are longer than stock brake hoses depending on application.
| Buy | Quantity | Part Number | Description | Price | In Stock | Click for Zoom |
|---|---|---|---|---|---|---|
| Add to Cart | 086-30K-S |
Stainless Steel Braided Front Brake Line To Wheel-7 1/2 inches long Fits 8/80-1/90 FJ60 & FJ62 - Depending on application, this hose is longer than stock - For Stainless Steel Braided Brake Hose Kit see #086-30KA-KIT WARNING: Cancer and Reproductive Harm — www.p65warnings.ca.gov |
$29.00 |
|
||
|
Stainless Steel Braided Front Brake Line To Wheel-7 1/2 inches long Fits 8/80-1/90 FJ60 & FJ62 - Depending on application, this hose is longer than stock - For Stainless Steel Braided Brake Hose Kit see #086-30KA-KIT WARNING: Cancer and Reproductive Harm — www.p65warnings.ca.gov |
||||||
| Add to Cart | 086-31K-S |
Stainless Steel Braided Front Brake Line-20 inches long Fits 8/80-1/90 FJ60 & FJ62 - Depending on application, this hose is longer than stock - For Stainless Steel Braided Brake Hose Kit see #086-30KA-KIT WARNING: Cancer and Reproductive Harm — www.p65warnings.ca.gov |
$45.00 |
|
||
|
Stainless Steel Braided Front Brake Line-20 inches long Fits 8/80-1/90 FJ60 & FJ62 - Depending on application, this hose is longer than stock - For Stainless Steel Braided Brake Hose Kit see #086-30KA-KIT WARNING: Cancer and Reproductive Harm — www.p65warnings.ca.gov |
||||||
| Add to Cart | 086-32K-S |
Stainless Steel Braided Rear Brake Line-20 inches long Fits 8/80-7/87 FJ60 - Depending on application, this hose is longer than stock - For Stainless Steel Braided Brake Hose Kit see #086-30KA-KIT WARNING: Cancer and Reproductive Harm — www.p65warnings.ca.gov |
$45.00 |
|
||
|
Stainless Steel Braided Rear Brake Line-20 inches long Fits 8/80-7/87 FJ60 - Depending on application, this hose is longer than stock - For Stainless Steel Braided Brake Hose Kit see #086-30KA-KIT WARNING: Cancer and Reproductive Harm — www.p65warnings.ca.gov |
||||||
| Add to Cart | 086-32L-S |
Stainless Steel Braided Rear Brake Line-20 inches long Fits 8/87-1/90 FJ62 - Depending on application, this hose is longer than stock - For Stainless Steel Braided Brake Hose Kit see #086-30KA-KIT WARNING: Cancer and Reproductive Harm — www.p65warnings.ca.gov |
$45.00 |
|
||
|
Stainless Steel Braided Rear Brake Line-20 inches long Fits 8/87-1/90 FJ62 - Depending on application, this hose is longer than stock - For Stainless Steel Braided Brake Hose Kit see #086-30KA-KIT WARNING: Cancer and Reproductive Harm — www.p65warnings.ca.gov |
||||||
| Add to Cart | 086-30KA-KIT |
Stainless Steel Braided Brake Hose Kit Fits 8/80-1/90 FJ60 & FJ62 - Comes with #086-30 front brake hose to wheel (qty 2), #086-31 front brake hose (qty 1), #086-32 rear brake hose (qty 1), retainer clips and copper sealing washers - Depending on application, these hoses are longer than stock WARNING: Cancer and Reproductive Harm — www.p65warnings.ca.gov |
$122.00 |
|
||
|
Stainless Steel Braided Brake Hose Kit Fits 8/80-1/90 FJ60 & FJ62 - Comes with #086-30 front brake hose to wheel (qty 2), #086-31 front brake hose (qty 1), #086-32 rear brake hose (qty 1), retainer clips and copper sealing washers - Depending on application, these hoses are longer than stock WARNING: Cancer and Reproductive Harm — www.p65warnings.ca.gov |
||||||
Back to Top
Click the NUMBERS in the blue squares for part listings
Click on the BLUE HIGHLIGHTED NUMBERS in the line drawings to display a COMPLETE part listing of that part number.
Part Numbers & Part Listings
1/90-1/98 80 Series
Without Anti-Lock
8/92-1/98 80 Series
Brake Actuator
Brake Actuator
1/90-1997 80 Series -
Load Sensing Proportion Valve (L.S.P.V.) #60 IS A USED ASSEMBLY
8/92-1/98 80 Series
8/92-1/98 With Anti-Lock
TECH NOTE: Stock and Stainless Steel Brake Line Lengths for parts #086-30, 31 & 32
FJ40, FJ55, FJ60 & FJ62
Stainless Braided Brake Hose Kits
Stainless Braided Brake Hose Kits
|
Brake Line Kit
|
Application
|
| 086-30BA-KIT |
Fits 7/70-9/75 FJ40
|
| 086-30BB-KIT |
Fits 9/75-7/80 FJ40
|
| 086-30CA-KIT |
Fits 8/80-1984 FJ40
|
| 086-30IA-KIT |
Fits 7/70-9/75 FJ55
|
| 086-30IB-KIT |
Fits 9/75-7/80 FJ55
|
| 086-30KA-KIT |
Fits 8/80-1/90 FJ60 & FJ62
|
Individual Stainless Braided Brake Hose
by Length and Application
by Length and Application
|
Brake Line
|
Length
|
Application
|
| #086-30A |
17 Inches
|
1958-7/70 FJ40
|
| #086-30A-A |
22 Inches
|
1958-7/70 FJ40
|
| #086-30B-S |
9 Inches
|
7/70-7/80 FJ40
|
| #086-30B |
8 1/2 Inches
|
7/70-7/80 FJ40
|
| #086-30C-S |
9 1/2 Inches
|
8/80-1984 FJ40
|
| #086-30C |
9 Inches
|
8/80-1984 FJ40
|
| #086-30I-S |
9 Inches
|
7/70-7/80 FJ55
|
| #086-30I |
8 1/2 Inches
|
7/70-7/80 FJ55
|
| #086-30K-S | 7 1/2 Inches |
8/80-1/90 FJ60 & FJ62 |
| #086-30K | 7 1/2 Inches |
8/80-1/90 FJ60 & FJ62 |
| #086-31A-S |
19 1/2 Inches
|
7/70-9/74 FJ40
|
| #086-31A |
14 1/2 Inches
|
7/70-9/74 FJ40
|
| #086-31B-S |
19 1/2 Inches
|
9/74-9/75 FJ40
|
| #086-31B |
14 1/2 Inches
|
9/74-9/75 FJ40
|
| #086-31C-S |
20 Inches
|
9/75-1984 FJ40
|
| #086-31C |
10 Inches
|
9/75-1984 FJ40
|
| #086-31G-S |
19 1/2 Inches
|
7/70-9/75 FJ55
|
| #086-31G |
17 Inches
|
7/70-9/75 FJ55
|
Individual Stainless Braided Brake Hose
by Length and Application
by Length and Application
|
Brake Line
|
Length
|
Application
|
| #086-31H-S |
19 1/2 Inches
|
9/75-7/80 FJ55
|
| #086-31H |
17 Inches
|
9/75-7/80 FJ55
|
| #086-31K-S | 20 Inches |
8/80-1/90 FJ60 & FJ62 |
| #086-31K | 11 3/4 Inches |
8/80-1/90 FJ60 & FJ62 |
| #086-32C-S |
19 1/2 Inches
|
7/70-7/80 FJ40
|
| #086-32C |
17 Inches
|
7/70-7/80 FJ40
|
| #086-32D-S |
20 Inches
|
8/80-1984 FJ40
|
| #086-32D |
17 Inches
|
8/80-1984 FJ40
|
| #086-32G-S |
19 1/2 Inches
|
1968-9/74 FJ55
|
| #086-32G |
17 1/2 Inches
|
1968-9/74 FJ55
|
| #086-32H-S |
19 1/2 Inches
|
9/74-7/80 FJ55
|
| #086-32H |
17 1/2 Inches
|
9/74-7/80 FJ55
|
| #086-32L-S |
19 1/2 Inches
|
8/87-1/90 FJ62
|
| #086-32K-S | 20 Inches |
8/80-8/87 FJ60 |
| #086-32K | 14 Inches |
8/80-8/87 FJ60 |
| #086-32L-S | 20 Inches |
8/87-1/90 FJ62 |
| #086-32L | 15 Inches |
8/87-1/90 FJ62 |
Click outside table to close window
 BRAKE LINE & HOSE COPPER WASHERS (GASKETS) |
|||||
|---|---|---|---|---|---|
| 0 | Application | Qty | Fits # | Brake Hose | Brake Union / Banjo Bolt |
| 1 | 1958-7/70 FJ40 | 2 | 086-33A | 086-30 Front Wheels | 086-10 1 per side |
| 2 | 1958-7/70 FJ40 | 1 | 086-33A | 086-32 Rear Axle | 086-14 |
| 3 | 1968-7/70 FJ55 | 2 | 086-33B | 086-30 Front Wheels | 086-10 1 per side |
| 4 | 1968-7/70 FJ55 | 1 | 086-33B | 086-32 Rear Axle | 086-14 |
| 5 | 7/70-9/75 40 & 55 | 2 | 086-90A | 086-30 Front Wheels | 086-10 1 per side |
| 6 | 7/70-9/75 40 & 55 | 1 | 086-90A | 086-31 Front Axle | 086-71 |
| 7 | 7/70-9/75 40 & 55 | 1 | 086-33B | 086-32 Rear Axle | 086-14 |
| 8 | 9/75-7/80 40 & 55 | 2 | 086-90B | 086-30 Front Wheels | 086-10 1 per side |
| 9 | 9/75-7/80 40 & 55 | 1 | 086-90B | 086-31 Front Axle | 086-71 |
| 10 | 9/75-7/80 40 & 55 | 1 | 086-33C | 086-32 Rear Axle | 086-14 |
| 11 | 1/90-8/92 FJ80 | 4 | 086-90M | 086-30 Front Wheels | 086-58 2 per side |
| 12 | 8/92-1/98 FZJ80 | 4 | 086-90N | 086-30 Front Wheels | 086-58 2 per side |
| 13 | 8/92-1/98 FZJ80 | 4 | 086-59N | 086-57 Rear Wheels | 086-58 2 per side |
